Aug 16,  · Wally Anderson of Synergy Air explains how to use a Pin Molex Connector. Push the terminal pin in all the way until it snaps in place. The terminal pins may come on a roll. Break them off one by one, and cut away with snippers any remaining material used to hold the pins together. The springy pins shown above make for a female Molex connector.

Then once you are sure, put some tape on it or something so that you can be remember which wire is which. Then you can start stripping your wires, strip the 4 wires form the molex plug, and then strip 2 pieces of wires on both sides so that you can use it to connect the power supply to the voltage regulator. Then you can start to tin the wires on the stripped sides. This is done so that the strands dont go everywhere and are together, also to make sure that the strands are connected to each other.

You can the begin to solder the small pieces of wire to the voltage regulator. Make sure that the wires are being soldered onto the input side of the regulator. Also make sure that there is a good connection from the wire onto the regulator. Once the input wires have been soldered onto the regulator, you can then solder on the molex plug on the output side. Be sure to connect the RED and one of the black wires to the voltage regulator. Once the molex plug has been connected to the voltage regulator, you can then connect up the YELLOW and the how to find square feet of house black wire.

I have simply twisted the wires together as the will be going into a block terminal connector, there was no need to solder. This step is not necessary for everyone as not all of you will have a variable voltage regulator, but what you simply do is turn the screwdriver one way until you see the voltage drop to what you need to. I had set my regulator to give out 4. I could make it go up to the 5 Volts but I decided to leave it a tenth of a volt lower as the full output of the "12Volt adapter" was only really around Be sure to insulate the voltage regulator and wires, or make sure that they don't come into contact with each other causing a short.

Did you make this project? Share it with us! What is the weather in melbourne in october Made It! Reply Upvote.

Step 1: Decide Which Wire Is Which

Nov 26,  · Step 1: Stripping Wire and Adding Power Connectors Begin by stripping back enough wire to ensure proper connection when crimping on the power connectors. Load the un-crimped power connector into the crimping tool. Feed the stripped wire into the . Make sure that the wires are being soldered onto the input side of the regulator. Also make sure that there is a good connection from the wire onto the regulator. Once the input wires have been soldered onto the regulator, you can then solder on the molex plug on the output side. installation instructions. Installation instructions for Molex’s range of products and solutions including enclosures, jacks, outlets, patch panels and more.

Adding connectors to wires helps with connectivity and allows for plug and play compatibility with electronic and electrical devices. This guide will provide an overview of adding and removing Molex connectors and housing to wires and the how-to process of doing so.

All the connectors and housing used in this tutorial are rated for usage with 18 to 24 AWG wire. However, similar Molex accessories can be used. The connector housing requires the use of male Molex metal pins and female Molex connectors. The receptacle housing will contain the female power connectors, and the plug housing will contain the male power connectors. Begin by stripping back enough wire to ensure proper connection when crimping on the power connectors.

Feed the stripped wire into the connector and then clamp down on the crimping tool. Once completed, release the tool. The crimped wires can now be fed into the connector housing.

The orientation of the wires can be based strictly off preference or may be required to follow a certain pin layout, depending on the type of system that you are working with. Female Power Connector and Male Housing. The power connectors have hooks that allow the connectors to latch into the connector housing. Once the crimped wire has been inserted into the housing, it will be difficult to remove.

However, there is a method of removing the wire from the housing without damaging the power connector. Since there are two hooks keeping the connectors in place within the housing, they will need to be pushed back to release the wires.

In this tutorial, we are using flat header pins that are used to release the hooks. This is completed by pushing the header pin into the thin gap between the metal power connector and the plastic on both sides of the housing. Removing the wires without damaging the connectors is a simple method of enabling users to switch the polarity of actuator wires without having the need to obtain additional Molex connectors or Molex Housing. More by the author:. About: Progressive Automations is your primary source for electric linear actuators, motion control systems and automation accessories.

For over a decade, we have supplied various industries with top quality automati… More About Progressive Automations ». Load the un-crimped power connector into the crimping tool. Did you make this project? Share it with us! I Made It! Ant Decorations Light Up at Night.
